High Pressure Diffuser

Accessories Portable

Get A Quote
Handheld 2016

The Mini Multiplexer communicates via MODBUS/ASCII or MODBUS/RTU and was designed with two RJ-45 connectors to allow daisy-chaining with other RS-485 instruments. The Mini Multiplexer is compatible with SOLAIRs and other Lighthouse Instruments on a daisy-chain when all are running MODBUS/ ASCII.

Power, Analog Inputs and Digital Outputs are connected via screw terminals for easy field installation and service of the unit. Connection to a variety of sensors and devices is possible without special connectors or tools. The REMOTE Mounting Kit option provides additional flexibility for mounting theMini Multiplexer.

  • Process Qualification
  • Semiconductor Process Monitoring
  • Flat Panel Process Monitoring
  • Process Trend Analysis

  • Supports 0.1μm at 1 CFM
  • May be Used With Any Inert Gas
  • Stainless Steel Construction
  • Easy Set Up
  • Simple Installation
  • Fast Purge and Cleanup
  • Stainless Steel Construction

  • Output at Near Atmospheric Pressure
  • Small Footprint
  • Easy System Integration
  • International Sales and Service Support
  • Low Cost of Ownership

Specifications

Specifications

Description: Isokinetic High Pressure Diffuser, Vented Version Isokinetic High Pressure Diffuser, Ported Version
Materials: Stainless Steel with Nitrile (Buna-N)
and Fluorocarbon (Viton) O-Rings
Stainless Steel with Nitrile (Buna-N)
and Fluorocarbon (Viton) O-Rings
Inlet Pressure Range: 30 to 150 psi [2 to 10.3 bar] 30 to 150 psi [2 to 10.3 bar]
Outlet Flow Rate: 0.1 CFM or 1 CFM 0.1 CFM or 1 CFM
Flow Control: Metal Orifice Metal Orifice
Isokinetic Sampling Point: Adjustable over the Inlet Pressure Range Adjustable over the Inlet Pressure Range
Sample Fluid: Pressurized Air, Nitrogen and Inert Gases Pressurized Air, Nitrogen and Inert Gases
Inlet and Outlet Ports: 1/4” Metal Gasket High Purity VCR Fitting
3/8” Compression, Union Fitting
1/4” Metal Gasket High Purity VCR Fitting
3/8” Compression, Union Fitting
Diameter: 1.31” [3.3 cm] at large cap 1.31” [3.3 cm] x 3.08” [7.8 cm]
Length: 8.14” [20.7 cm] at the 30 psi setting and
9.87” [25.1 cm] at the 150 psi setting
9.1” [23.1 cm] at the 30 psi setting and
10.83” [27.5 cm] at the 150 psi setting
Weight: 1.11 lbs [0.5 kg] 1.65 lbs [0.75 kg]
Cleanability: Easily disassembled and cleaned;
replaceable o-rings
Easily disassembled and cleaned;
replaceable o-rings
